    Servo Motor CNC Turning Lathe Machine 4 stations CNC Metal Lathe CAK6385

    Ask Lasest Price
    Brand Name :
    Model Number : CAK6385
    Certification : CE ISO
    Supply Ability : 1000 Sets per Year
    Price : Negotiable
    Delivery Time : 30-40days
    • Product Details
    • Company Profile

    Servo Motor CNC Turning Lathe Machine 4 stations CNC Metal Lathe CAK6385

    Servo Motor CAK6385 Cnc Lathe Machine Price Cnc Turning Tool Machine Lathe Metal Manufacturer


    Product Introduction

    CAK63 SERIES

    • The span of the guide rail is 324 mm, the depth of quenching layer is 2-3 mm, and the hardness of the guide rail is 52HRC.
    • X-axis fast moving is 6m/min, Z-axis fast moving is 12m/min.
    • First patented hydraulic gear-shifting bed head structure is convenient to operatewith high precision and reliability
    • The weight of trapezoidal integrated heavy bed increase 30%, but also the U-shaped bar lift the rigidity.
    • External main servo motote save space,which is easy maintenance
    • Full-functional two-axis transmission structure can improve processing accuracy
    • T-shaped trough reinforced structure of tailstock increase stability
    • Large waterproof tank, the waterproof structure from plugging to sparse, increase the waterproof performance of the whole machine
    Machine Parameters

    ItemUnitCAK6385CAK63135CAK63285
    Max workpiece lengthmm100015003000
    Max turning lengthmm85013502850
    Maximum swing diameter on bedmm630630630
    Maximum turning diameter on slidemm350350350
    Max turning diametermm630630630
    spindle passing bore diametermm104104104
    spindle taperA2-11A2-11A2-11
    spindle speedHydraulic four-gear
    Spindle speed ranger/min17-1000
    Chuck diametermm315315315
    Max. powerkW111515
    X-axis fast moving speedm/min6
    Z-axis fast moving speedm/min10
    Tailstock sleeve diametermm100
    Tailstock sleeve strokemm250
    Tailstock spindle taper taperMohs5#
    Standard tool holder formVertical 4 station
    External knifemm32x32
    PrecisionIT6~IT7
    Machine weightTotal weightkg520055506950
    Machine tool appearanceLength × width × heightmm3410x2010x17803860x2010x17805360x2010x1780

    Product advantages
